- 【High Performance】CPU: Allwinner H3, Quad-core Cortex-A7 Up to 1.2GHz, Memory: 512MB DDR3 RAM 8G eMMC. OS/Software: U-boot,Ubuntu,Ubuntu-Core,FriendlyWrt, Armbian and etc.
- 【Geek's Choice】The NanoPi NEO Core ARM Board has ESD protection for its MicroUSB port and TF card slot. In addition the NEO Core can have an optional onboard eMMC flash which is preferred by industrial customers.
- 【SDK Carrier Board】The Mini Shield for NanoPi NEO Core/Core2 is a custom SDK carrier board developed for the NanoPi NEO Core and NanoPi NEO Core2. It has Ethernet port, serial debug port, audio, USB port and etc.
- 【Rich interfaces】1 x Serial debug port for connecting a serial communication board, 1 x Ethernet port. 2 x USB Host ports; 1 x JMS567 USB to SATA IC and 1 x M.2 SSD interface for connecting a 2242 SSD. Room for an SPI Flash(SOP8-200mil) is reserved. Users can solder an SPI flash on the board.
- 【Raspberry Pi Dimension】The NanoPi NEO Mini Shield has the same dimension and mounting holes as those of a Raspberry Pi. The whole board can be well fit into a RPi's case
-Specification-
CPU: Allwinner H3, Quad-core Cortex-A7 Up to 1.2GHz
DDR3 RAM: 512MB DDR3 RAM
Storage: 8GB eMMC
MicroSD Slot x 1
MicroUSB: OTG and power input
GPIO: two 2.54mm spacing 12x2pin header,one 2.54mm spacing 10x2pin header
Connectivity: 10/100M Ethernet(6Pin, included in 2.54mm pitch pin header)
USB Host x3(included in 2.54mm pitch pin header)
Debug Serial Port(4Pin, included in 2.54mm pitch pin header )
Audio input/output Port(4Pin, included in 2.54mm pitch pin header )
GPIO:It includes UART, SPI, I2C, IO etc
PC Size: 40 x 40mm
Power Supply: DC 5V/2A
Temperature measuring range: -20℃ to 70℃
OS/Software: U-boot，Ubuntu-Core
Weight: 6.35g(WITHOUT Pin-headers)
-Package Content-
NanoPi NEO Core Motherboard Combo x1
